Techno Trend TT-budget S-1401 DVB-S PCI card
S-1401
The S-1401 is a universal 32bit PCI card.
SAA7146AH
TDA10086HT
Firmware
The firmware can be downloaded from this site as TT_PCI_2.19h_28_11_2006.zip. The link in the kernel documentation script 'get_dvb_firmware' appears to be broken (2.6.26.5).
Links
- http://www.technotrend.de/2701/TT-budget__S-1401.html
- TechSpec_TT-budget_20S-1401.pdf
- http://linuxtv.org/wiki/index.php/Philips_SAA7146
- http://linuxtv.org/wiki/index.php/TechnoTrend
- Linux Kernel Driver Database http://cateee.net/lkddb/web-lkddb/DVB_BUDGET.html
- http://www.mail-archive.com/fedora-list@redhat.com/msg15878.html
Appendices
lspci -vv
03:02.0 Multimedia controller: Philips Semiconductors SAA7146 (rev 01)
Subsystem: Technotrend Systemtechnik GmbH DVB S-1401
Control: I/O- Mem+ BusMaster+ SpecCycle- MemWINV- VGASnoop- ParErr- Stepping- SERR- FastB2B- DisINTx-
Status: Cap- 66MHz- UDF- FastB2B+ ParErr- DEVSEL=medium >TAbort- <TAbort- <MAbort- >SERR- <PERR- INTx-
Latency: 64 (3750ns min, 9500ns max)
Interrupt: pin A routed to IRQ 26
Region 0: Memory at fc8ffc00 (32-bit, non-prefetchable) [size=512]
Kernel driver in use: Emagic Audiowerk 2
Kernel modules: budget, snd-aw2
lspci -vvn
03:02.0 0480: 1131:7146 (rev 01)
Subsystem: 13c2:1018
Control: I/O- Mem+ BusMaster+ SpecCycle- MemWINV- VGASnoop- ParErr- Stepping- SERR- FastB2B- DisINTx-
Status: Cap- 66MHz- UDF- FastB2B+ ParErr- DEVSEL=medium >TAbort- <TAbort- <MAbort- >SERR- <PERR- INTx-
Latency: 64 (3750ns min, 9500ns max)
Interrupt: pin A routed to IRQ 26
Region 0: Memory at fc8ffc00 (32-bit, non-prefetchable) [size=512]
Kernel driver in use: Emagic Audiowerk 2
Kernel modules: budget, snd-aw2
